# Kohn-Sham random-phase approximation

Electron correlation energies within the random-phase approximation can be calculated by the programs **DIRPA**, **RPAX2** and **ACFDT** that are subdirectives of the driver command **KSRPA**. These methods should be used in conjunction with Kohn-Sham reference determinants, i.e., orbitals and orbital energies from a preceeding DFT calculation should be supplied. An alterntive implementation of various RPA electron correlation methods by Julien Toulouse and co-workers is described in the subsection Random-phase approximation (RPATDDFT) program.

A typical input to calculate the RPAX2 correlation energy is given by:

basis={ set,orbital; default,<basis> set,mp2fit; default,<basis>/mp2fit} ks,pbe {ksrpa; rpax2,orb=2100.2}

All methods are implemented using density-fitting of the two-electron repulsion integrals, see Refs. [2,4]. Because of this, auxiliary basis sets for fitting occupied-virtual orbital pairs have to be given, see section auxiliary basis sets for density fitting or resolution of the identity. No point-group symmetry can be used for all methods described in this section.

References:

**RPA:**

$[1]$ F. Furche, Phys. Rev. B **64**, 195120 (2001).

**RPAX2:**

$[2]$ A. Heßelmann, Phys. Rev. A **85**, 012517 (2012).

$[3]$ A. Heßelmann, Top. Curr. Chem. **365** 97 (2015)

**ACFDT(ALDA):**

$[4]$ A. Heßelmann and A. Görling, J. Chem. Theory Comput. **9**, 4382 (2013).

## DIRPA program

The direct RPA program (implemented with the algorithm described in [1]) has the following options:

**ORB**record number containing the orbital coefficients and eigenvalues (mandatory)**AUXBAS**string containing the label for the auxiliary basis set (default`MP2FIT`

)**CORE**number of core orbitals (which are not correlated)**MAXIT**maximum number of iterations (default ’40’)**THREN**threshold for convergence of energy (default ’1d-8’)**FMIX**mixing factor for the amplitude update $T^{\text{new}}=f T^{\text{old}}+(1-f)T^{\text{new}}$ (default: ’0.4d0’)**RESTART**logical flag to enable a restart from an unfinished calculation. For this, the 3-index Coulomb integrals (Lc.dat) and the two amplitude files (T0.dat and T1.dat) are required if MODE=1 or MODE=2, see below. In case of MODE=3, Molpro’s file 4 needs to be saved in the previous calculation (using, e.g.,`file,4,rpa.dat`

at the beginning of the input file) (default: ’0’)**NOMAX**maximum number of $N_{\text{aux}}\times N_{\text{virt}}$ batches to be kept in memory ($N_{\text{aux}}$: number of auxiliary basis functions, $N_{\text{virt}}$: number of virtual orbitals). (assumes: MODE=1, default: ’50’)**MODE**can have the values ’0’,’1’,’2’ and ’3’. If MODE=0 all 3-index quantities are kept in memory. If MODE=1, external 3-index integral and amplitude files are written (to the wavefunction directory). With MODE=2 larger batches of amplitudes can be read/written as specified with NOMAX. MODE=3 is a duplicate of MODE=1, but the 3-index quantities are written to an internal Molpro file (default: ’MODE=3’)**L**string containing the scratch file name for the 3-index Coulomb integrals (default: ’Lc.dat’)**T0**string containing the scratch file name for the amplitudes (default: ’T0.dat’)**T1**string containing the scratch file name for the amplitude updates (default: ’T1.dat’)**SOSEX**logical flag, set to SOSEX=1 if the SOSEX energy shall be calculated after convergence (default: ’SOSEX=0’)

Note that in case of MODE=1 or MODE=2 it is recommended to have the wavefunction (wfu) directory located on a scratch partition. E.g., add the command line option `-W /scratch/$USER/wfu`

to the Molpro command.

## RPAX2 program

The RPAX2 method is an extension to the RPA and accounts for higher order particle-hole pair exchange contributions [2,3]. The RPAX2 program has the same options as the DIRPA program, see section DIRPA program. The following list shows a few additional ones that can be used:

**DIR**if set to DIR$\ne$0 this enables a direct RPA calculation (default ’0’)**MEM**if set to MEM$\ne$0 the 3-index Coulomb integrals and the amplitudes are kept in memory (default: 0)

Spin-unrestricted calculations can be done using the **URPAX2** program. In this case the orbitals from a preceeding unrestricted Kohn-Sham calculation have to be passed to the program (via the `ORB`

key).

## ACFDT program

The ACFDT (adiabatic connection fluctuation-dissipation theorem) method is an alternative approach to derive the RPA. If used in conjunction with local adiabatic exchange-correlation kernels, the method can also describe electron-electron interaction contributions beyond the RPA. Currently, the ALDA xc-kernel can be used in the program (ACFDT(ALDA) method), see also Ref. [4]. The **ACFDT** program has the following options:

**ORB**record number containing the orbital coefficients and eigenvalues (mandatory)**AUXBAS**string containing the label for the auxiliary basis set (default`MP2FIT`

)**CORE**number of core orbitals (which are not correlated)**NFREQ**number of frequency quadrature points (default ’20’)**NCOUP**number of coupling strength quadrature points (default ’7’)**GRIDTHR**threshold for grid accuracy (default ’1d-10’)**THRKERN**threshold for density in kernel integration (default ’1d-12’)**XFAC**factor tor ALDA exchange contribution (default ’1d0’)**CFAC**factor tor ALDA correlation contribution (default ’1d0’)**NOXC**can be set to ’NOXC$\ne 0$’ if no ALDA xc-contribution shall be added to the electron-electron interaction (which then corresponds to a standard direct RPA calculation) (default ’0’)**OMQUAD**set to ’1’ for Gauss-Chebyshev quadrature and ’2’ for Gauss-Legendre quadrature (default ’2’)**W0**parameter for Gauss-Legendre quadrature, see R. D. Amos*et al.*,*J. Phys. Chem.***89**(1985) 2186**L3ALPHA**logical flag to switch on calculation of coupling-strength dependent xc-kernel integrals (deactivated by default)**FXC2IDX**logical flag for performing a double density fitting approximation of the electron-electron interaction matrix (deactivated by default)**FXC2**a switch for various approaches to calculate the 2-index xc-kernel integrals (default ’1’)**THRDUM**threshold for density on dummy centre quadrature points (if set to a large value, the dummy centre quadrature points are skipped completely) (default ’0d0’)**SING**logical flag to enable handling of singularity of 2-index xc-kernel integrals, see also the following two options (enabled by default)**ESHIFT**corresponds to $\epsilon$ in $f=1-\rho/(\rho+\epsilon)$ (default: ’1d-5’)**FSCAL**corresponds to $s$ in $\rho=\rho+s\cdot f$ (default ’1d-4’)

The ACFDT(ALDA) method is ill-defined for short electron-electron distances, see Ref. [4] and F. Furche and T. Van Voorhis, J. Chem. Phys. **122**, 164106 (2005). Because of this, the method does not have a defined basis set limit and the **ACFDT** program should not generally be used to calculate ACFDT(ALDA) correlation energies. Instead, the **ACFDT2** should be utilised which implements the hybrid approach as described in Ref. [4] and which has, in addition to the ones given above, the following options:

**SCAL**scaling factor for the RPA kernel (used for short electron-electron distances) (default ’1d0’)**MU**range-separation parameter. If not used, the program does not perform a correction for the short range electron-electron interaction.

For applying the correction as described in Ref. [4], the vaules of `SCAL`

and `MU`

have to be set to the values `SCAL=0.6`

and `MU=2d0`

.

The **ACFDT3** program implements an approximation to the ACFDT(ALDA) method assuming that the xc-kernel matrix depends linearly on the coupling strength (which is true for the exchange contribution but not, in general, for the correlation contribution to the kernel). Within this approximation the coupling-strength integration can be done analytically leading to a performance improvement over the **ACFDT** and **ACFDT2** programs. The options for **ACFDT3** are identical to the ones given above for **ACFDT** and **ACFDT2**.

## Random-phase approximation (RPATDDFT) program

The random-phase approximation program (`rpatddft`

) can be used to calculate RPA correlation energies after a SCF calculation. Additionnally, it can be used to calculate dynamic dipole polarizabilities, C$_6$ dispersion coefficients, and excitation energies. The program currently works without point-group symmetry.

List of the main keywords:

`ECORR, <list of methods>`

Calculation of RPA correlation energies [1] (see options below)

`PROPERTIES, <list of methods>`

Calculation of dynamic dipole polarizabilities and C$_6$ dispersion coefficients [10] (see options below)

`EXCIT, <list of methods>`

Calculation of excitation energies [11] (see options below)

Record for input orbitals (required).`ORB,<orbrec>`

as well as contextual options (see later for an explanation on this):

`INTAC,NLAMBDA=<n>[,LAMBDA=<lambda>,WEIGHT=<weight>]`

Number of quadrature points for the Gauss-Legendre numerical integration along the adiabatic connection for RPA calculations (default is 7). If `LAMBDA`

and `WEIGHT`

are given, assumes a one-point quadrature with given abscissa and weight.

`INTFREQ,METHFREQ=<methfrq>,NFREQ=<nfreq>`

Options for the numerical integration over the frequency variable of RPA calculations. `METHFREQ`

governs the type of quadrature used (0(default) is Gauss-Chebyshev, 1 and 2 are Gauss-Legendre, 3 is Clenshaw-Curtis) and `NFREQ`

governs the number of quadrature points (default is 16).

Use the solid-state variant when performing DIEL calculations.`DIELMODE,mode`

and global options, shared by all commands inside the `rpatddft`

block:

Check matrices stability conditions in RPA calculations. When used without an`STAB`

`ECORR`

,`EXCIT`

or`PROPERTIES`

keyword, check the Hessian and RPA matrices eigenvalues and do nothing more.`DFTKERNEL,<funcx>[,<funcc>]`

Specify the exchange and correlation kernel for `EXCIT`

(if only one argument is given, it is understood to be the exchange-correlation kernel).

Computes C6 coefficients from last two saved polarizabilities.`C6`

Tamm-Dancoff approximation for`TDA`

`EXCIT`

and`PROPERTIES`

.The MP2 energy is calculated in certain situations where it is available almost for free, provided that some matrices are allocated. This behavior can be switched off by this`NOMP2`

`NOMP2`

keyword.For spin-unrestricted calculations, use a formalism where matrices are of $\alpha\alpha+\alpha\beta+\beta\alpha+\beta\beta$ dimensions (the default is to use a formalism with a nospinflip/splinflip block structure)`NOSPINBLOCK`

Exclude spin-flip dimensions of unrestricted RPA calculations that use the`NOSPINFLIP`

`NOSPINBLOCK`

formalism (not suitable for all RPA variants).Write files with eigenvalues, virtual orbital energies, dipole moments, dipole velocities, dipole accelerations and amplitudes from a TDA calculation`WRITEFILE`

#to comment#`VIAXPY`

Specify the two-electron integral transformation routine: 0 (still the default for spin-unrestricted and gradient calculations) is the ‘old’ one, 1 is the ‘old’ one that has been cleaned up, and 2 (default otherwise) is a much more efficient transformation using Molpro’s`INTEGRAL,<nbr>`

`transform`

routine.Explicitly specify the number of occupied orbitals (useful for fake pseudopotential calculations).`OCC,<nocc>`

Specify core orbitals (default: last specified core orbitals or, if none, atomic inner shells)`CORE,<core>`

Level of print expected from the output (from 0(default) to 3).`PRINT,<nbr>`

Level of print of integrals (AO,MO,Orbtials,…), from 0 to 4.`PRINT_INT,<nbr>`

If greater or equal to 1, will print out information on time spent in routines.`PRINT_TIME,<nbr>`

Calculation of RPA correlation energies `ECORR, <list of methods>`

If no method is given, a `SO2-RCCD`

calculation will be done (see below).

There are two main RPA *variants* [1]: dRPA (direct RPA, without the inclusion of an Hartree-Fock exchange kernel in the response function) and RPAx (with the Hartree-Fock exchange kernel included in the response function).

There are four main *formulations* in which the RPA equations can be derived. The adiabatic-connection fluctuation-dissipation theorem (ACFDT) equation involves integrations both over frequency and coupling constant: an analytical integration along the frequency variable followed by a quadrature on the coupling constant yields the adiabatic connection formulation (AC) [1], while an analytic integration on the coupling constant followed by a numerical integration over the frequency yields the dielectric formulation (DIEL) [2]. Two other formulations are obtained when the two integrations are carried out analytically: the plasmon formula (PLASMON) [1] and the ring coupled cluster doubles formulation (RCCD) [3]. These four formulations are not in general equivalent.

Most variants+formulations can readily by used in a spin-unrestricted context [6]. This is implemented in the code and does not need any further input from the user: the RPA program recognizes the spin-unrestricted character of a SCF calculation that was done beforehand and acts accordingly.

Gradients of most of the RCCD-formulation RPA energies are available, both without range-separation with RHF orbitals and with range-separation with RSH orbitals [9]. The calculations are triggered by the presence of the keyword `FORCE`

or `OPTG`

*after* the energy-related section (see examples at the end of the section).

The user can test the RPA program using `make rpatddfttest`

, which proposes a variety of tests for RPA correlation energy calculations.

The keywords for the methods are constructed on the model:

`<variant>-<formulation>-<alternative>`

For the AC formulation, the available methods are:

dRPA calculation (see Refs. [1] and [4]).`DRPAI-AC`

dRPA calculation, using antisymmetrized two-electron integrals (see Refs. [1] and [4]).`DRPAII-AC`

RPAx calculation (see Refs. [1] and [5]).`RPAXI-AC`

RPAx calculation, using antisymmetrized two-electron integrals (see Refs. [1] and [5]).`RPAXII-AC`

dRPA calculation using an alternative derivation (see Ref. [7]).`DRPAI-AC-ALT`

RPAx calculation using an alternative derivation (see Ref. [7]).`RPAXI-AC-ALT`

dRPA calculation without integration along the adiabatic connection (using the “kinetic” and “potential” contributions, sometimes called the “alternative plasmon formula”, see Ref. [1]).`DRPAI-AC-NOINT`

RPAx calculation without integration along the adiabatic connection (using the “kinetic” and “potential” contributions, sometimes called the “alternative plasmon formula”, see Ref. [1]).`RPAXII-AC-NOINT`

For the DIEL formulation, the available methods are:

dRPA calculation (see Ref. [2]).`DRPAI-DIEL`

dRPA-IIa approximation (see Ref. [2]).`DRPAIIA-DIEL`

RPAx-Ia approximation (see Ref. [2]).`RPAXIA-DIEL`

For the RCCD formulation, the available methods are:

dRPA-I calculation (see Ref. [3]).`DRPAI-RCCD`

RPAx-II calculation (Szabo-Ostlund variant 1 is calculated too, see Ref. [3]).`RPAXII-RCCD`

Szabo-Ostlund variant 2 (see Ref. [3]).`SO2-RCCD`

dRPA-I+SOSEX correction (see Ref. [3]).`SOSEX-RCCD`

RPAX2 approximation (see Ref. [8]).`RPAX2-RCCD`

For the PLASMON formulation, the available methods are:

dRPA-I calculation (see Ref. [1]).`DRPAI-PLASMON`

RPAx-II calculation (see Ref. [1]).`RPAXII-PLASMON`

Note that to all these keywords are associated energy variables defined as :

`ECORR_VARIANT_FORMULATION_ALTERNATIVE`

(see the examples below).

Example of a dRPA-I calculation using the PBE functional:

{rks,pbe,orbital,2101.2} {rhf,start=2101.2,maxit=0} {rpatddft; orb,2101.2; ecorr,DRPAI-AC } e=ECORR_DRPAI_AC

Example of a range-separated RPAx-I calculation using the short-range PBE exchange-correlation functional and the range-separated parameter mu=0.5:

{int;erf,0.5} {rks,exerfpbe,ecerfpbe;rangehybrid;orbital,2101.2} {rpatddft; orb,2101.2; ecorr,RPAXI-AC }

Example of several RPA calculations in the same run:

{rhf,orbital,2101.2} {rpatddft; orb,2101.2; ecorr,DRPAI-AC,RPAXII-RCCD,DRPAI-DIEL } e1=ECORR_DRPAI_AC e2=ECORR_RPAXII_RCCD e3=ECORR_DRPAI_DIEL

(this way, the calculations are done with the same transformed integrals, *i.e.* without redoing the integral transformation).

Example of a dRPA-I gradient calculation:

{rks,pbe,orbital,2101.2} {rpatddft; orb,2101.2; ecorr,DRPAI-RCCD } force

Example of a geometry optimization at the LDA+dRPA-I level:

{int;erf,0.5} {rks,exerf,ecerf;rangehybrid;orbital,2101.2} {rpatddft; orb,2101.2; ecorr,DRPAI-RCCD } optg

Calculation of properties, excitation energies and oscillator strengths

`EXCIT, METHOD=<method>`

The `EXCIT`

calculations output shows the excitation energies in ua, eV and nm, the oscillator strengths in length and velocity gauge, as well as the major excitations involved in each mode. The methods available are:

Direct random-phase approximation (or time-dependent Hartree).`DRPA`

Time-dependent Hartree-Fock.`TDHF`

Time-dependent density-functional theory.`TDDFT`

Range-separated time-dependent density-functional theory [11].`RS-TDDFT`

The exchange density functionals (FUNCX) available are:

(short-range LDA exchange density functional for the erf interaction [12]).`LDAXERF`

The correlation density functionals (FUNCC) available are:

(Perdew-Wang-92 LDA correlation density functional)`LDAC`

(short-range LDA correlation density functional for the erf interaction [13]).`LDACERF`

Example of a range-separated time-dependent density-functional theory calculation using the short-range LDA exchange-correlation functional and the range-separated parameter mu=0.5:

mu=0.5 {int;erf,mu;save} {rks,exerf,ecerf;rangehybrid;orbital,2101.2} {int} {setmu,mu} {rpatddft; orb,2101.2; excit,method=rs-tddft; dftkernel,funcx=ldaxerf,funcc=ldacerf }

Example of a TDHF-TDA calculation with writing of several files for interfacing with a real-time propagation code (see Ref. [14]):

{rpatddft; integral,1; writefile,transmom.dat,energies.dat,virtual.dat,transmom_v.dat,amplitudes.dat,transmom_a.dat; orb,2330.2; excit,method=tdhf; NOSPINBLOCK; tda}

The files are: `transmom.dat`

: transition moments in position form; `energies.dat`

: total energies of the states; `virtual.dat`

: virtual positive-energy orbitals; `transmom_v.dat`

: transition moments in velocity form; `amplitudes.dat`

: coefficients of excited-state wave functions over single-excited determinants; `transmom_a.dat`

: transition moments in acceleration form

References

$[1]$ J. G. Ángyán, R.-F. Liu, J. Toulouse, and G. Jansen, J. Chem. Theory Comput. **7**, 3116 (2011).

$[2]$ G. Jansen, B. Mussard, D. Rocca, J. G. Ángyán (in prep).

$[3]$ J. Toulouse, W. Zhu, A. Savin, G. Jansen, and J. G. Ángyán, J. Chem. Phys. **135**, 084119 (2011).

$[4]$ F. Furche, Phys. Rev. B **64**, 195120 (2001).

$[5]$ J. Toulouse, I. C. Gerber, G. Jansen, A. Savin, and J. G. Ángyán, Phys. Rev. Lett. **102**, 096404 (2009).

$[6]$ B. Mussard, P. Reinhardt, J. G. Ángyán, and J. Toulouse, J. Chem. Phys. (submitted).

$[7]$ Heßelmann, A., Görling, A., Phys. Rev. Lett. **106**, 093001 (2011).

$[8]$ Heßelmann, A., Phys. Rev. A **85**, 012517 (2012).

$[9]$ B. Mussard, P. G. Szalay, J. G. Ángyán, J. Chem. Theory Comput. **10**, 1968 (2014).

$[10]$ J. Toulouse, E. Rebolini, T. Gould, J. F. Dobson, P. Seal, J. G. Ángyán, J. Chem. Phys. **138**, 194106 (2013).

$[11]$ E. Rebolini, A. Savin, J. Toulouse, Mol. Phys. **111**, 1219 (2013).

$[12]$ J. Toulouse, A. Savin, and H.-J. Flad, Int. J. Quantum Chem. **100**, 1047 (2004).

$[13]$ S. Paziani, S. Moroni, P. Gori-Giorgi, and G. B. Bachelet, Phys. Rev. B **73**, 155111 (2006).

$[14]$ E. Coccia, B. Mussard, M. Lebeye, J. Caillat, R. Taieb, J. Toulouse, and E. Luppi, Int. J. Quant. Chem. **116**, 1120 (2016).
